V-MARK™ Reflective Material – Vehicle Conspicuity Markings #DB-SQA-180012 consists of microprismtic lenses that are intergrated in a transparent, smooth surface, tough and weather-resistant synthetic resin, sealed and backed with a pressure sensitive adhesive and paper liner.
DB-SQA-180012 is designed to use on truck, trailer, oil tanker, pick-up, farm equipment, industrial equipment and other vehicles. If they are applied to properly prepared surfaces, Vehicle Conspicuity Markings should provide a long time of field performance.
DB-SQA-180012 is made strictly according to FMVSS 108, ASTM D4956, and similar standards.
- Square Pattern
- DOT FMVSS 108
- PVC+PET Material
- 5+ Years Durability
- 6”White*6”Red Alternating
- Standard Shipping Dimensions 1” / 2” / 4”X 150ft Roll
- High Adhesion
- Good Flexibility
- Strong Reflection, Good Wide Angle
- Wear Resistance, Scratch Resistance
- Color Printed in the Inner Layer, Do not Fade
- Customized Size is Acceptable
- Customized Packaging is Acceptable
- Your Custom Logo Imprinting is Acceptable
- ...
- Truck
- Trailer
- Conrainer
- School Bus
- Emergency Vehicle
- Locomotive & Railcar
- Agriculture Vehicle
- ...
- Square Pattern
- DOT FMVSS 108
- PVC+PET Material
- 5+ Years Durability
- 6”White*6”Red Alternating
- Standard Shipping Dimensions 1” / 2” / 4”X 150ft Roll
- High Adhesion
- Good Flexibility
- Strong Reflection, Good Wide Angle
- Wear Resistance, Scratch Resistance
- Color Printed in the Inner Layer, Do not Fade
- Customized Size is Acceptable
- Customized Packaging is Acceptable
- Your Custom Logo Imprinting is Acceptable
- ...
- Truck
- Trailer
- Conrainer
- School Bus
- Emergency Vehicle
- Locomotive & Railcar
- Agriculture Vehicle
- ...
Technical Date
Square Pattern
DOT FMVSS 108
PVC+PET Material
5+ Years Durability
6”White*6”Red Alternating
Standard Shipping Dimensions 1” / 2” / 4”X 150ft Roll
Feature
High Adhesion
Good Flexibility
Strong Reflection, Good Wide Angle
Wear Resistance, Scratch Resistance
Color Printed in the Inner Layer, Do not Fade
OEM Service
Customized Size is Acceptable
Customized Packaging is Acceptable
Your Custom Logo Imprinting is Acceptable
...
Application
Truck
Trailer
Conrainer
School Bus
Emergency Vehicle
Locomotive & Railcar
Agriculture Vehicle
...
V-MARK™ Reflective Material – Vehicle Conspicuity Markings conforms to the photometry requirements of GRADE DOT-C2 showed in the following table when tested according to the retro reflective sheeting photometry procedure stated in FMVSS 108 Appendix G.
|
FMVSS 108 Retro Reflective Sheeting Photometry Requirements |
|||||||
|
OBSERVATION ANGLE (degrees) |
ENTRANCE ANGLE (degrees) |
MINIMUM PERFORMANCE |
|||||
|
GRADE DOT-C2 |
GRADE DOT-C3 |
GRADE DOT-C4 |
|||||
|
WHITE |
RED |
WHITE |
RED |
WHITE |
RED |
||
|
cd/lux/sq.m. |
cd/lux/sq.m. |
cd/lux/sq.m. |
cd/lux/sq.m. |
cd/lux/sq.m. |
cd/lux/sq.m. |
||
|
0.2° |
-4° |
250 |
60 |
165 |
40 |
125 |
30 |
|
30° |
250 |
60 |
165 |
40 |
125 |
30 |
|
|
45° |
60 |
15 |
40 |
10 |
30 |
8 |
|
|
0.5° |
-4° |
65 |
15 |
43 |
10 |
33 |
8 |
|
30° |
65 |
15 |
43 |
10 |
33 |
8 |
|
|
45° |
15 |
4 |
10 |
3 |
8 |
2 |
|
While use V-MARK™ Reflective Material – Vehicle Conspicuity Markings enhances visibility, no reflective material can guarantee absolute visibility, particularly in adverse weather conditions. Performance will vary depending upon actual use, exposure conditions and maintenance. Users should test reflective material to satisfy conformance to their own requirements.
